Overview

The horizontal 3-Phase test separator is a modular unit containing all the controls and measuring devices required to provide accurate well test data. The separator vessel is available in different diameters and lengths to suit any flow rate application. It provides a safe and efficient separation process, using internal components to maximize the separation process. Metering is performed on all three phases, utilizing turbine meters on the fluid legs and orifice or Coriolis meters on the gas. Protected with overpressure and level devices, they can if needed, be trailer mounted for ease of deployment.

Applicable Information

• Onshore operations
• Frac flow back cleanup, configured in three or four phase operation
• Well cleanup operations
• Single phase separation and measurement
• Extended production tests

Features

• Inlet bypasses to fluid and gas
• Dual vessel relief system
• Inlet relief system
• Internal components
  • Inlet deflector
  • Weir plate
  • Vortex breakers
  • High performance mist extractor
• Internal or external still wells

Benefits

• Modular design, quick rig up
• Dual vessel relief system
• ASME BPVC VIII and NACE compliant
• DNV certified skid
